Natural and Synthetic Ester Transformer for Wind 35kV & 66kV

Product Overview

This 35kV & 66kV Natural and Synthetic Ester Transformer for Wind combines the proven performance of liquid-immersed transformer technology with next-generation biodegradable ester fluid insulation — delivering superior environmental safety, fire protection, and longevity for onshore and offshore wind farm applications. Unlike conventional mineral oil transformers, ester-filled transformers offer a flash point exceeding 300°C (vs. ~130°C for mineral oil), dramatically reducing fire risk and allowing simplified fire protection requirements. The ester fluid is readily biodegradable — protecting sensitive ecosystems in offshore marine environments and environmentally protected onshore locations. With C5 anti-corrosion, IP54/IP55 protection, vibration-resistant structure, and certification to DNV GL, CE, CESI, and UL, this transformer is engineered for the full lifecycle demands of modern wind energy assets. Tested in a CNAS nationally accredited 8,000m² laboratory and manufactured in a 30,000-unit/year Guangdong facility with deployment across 60+ countries.

Applications

• Offshore Fixed-Bottom Wind Farms — Biodegradable ester transformer meeting offshore marine environmental protection requirements for North Sea, Baltic, and Asian offshore projects
• Floating Offshore Wind Platforms — Ester fluid reduces fire risk on floating platforms where firefighting access is limited and environmental impact is critical
• Onshore Wind Farm Substations — High fire point ester transformer simplifying fire protection requirements in remote or forested onshore wind farm locations
• Environmentally Sensitive Areas — Biodegradable ester fluid protecting water sources, nature reserves, and ecologically protected zones from transformer oil spills
• Offshore Boosting Stations — 35kV/66kV ester transformers for offshore collector and boosting substation platform installations
• Wind Turbine Nacelle Installation — Compact ester transformer with reduced fire risk ideal for in-nacelle step-up transformer applications
• Hybrid Wind + Storage Projects — Eco-friendly ester transformer for integrated wind and battery energy storage system substations
• Green Building & LEED Projects — Biodegradable ester transformer contributing to green building certification and ESG sustainability targets
• Marine & Port Facilities — DNV GL certified ester transformer for port electrification and marine facility power supply

• EPC Offshore Wind Turnkey Projects — Multi-certified DNV GL/CE/CESI/UL ester transformers for international EPC contractors on offshore wind projects
